Delta 3D Printing

2040 CLAY

DELTA WASP 2040 CLAY is a compact and professional clay 3D printing solution that can print up to 40 cm high.

Request a Quote

INDUSTRIALS

Architectural

Health

Space and Aviation

Machine

Automotive

DELTA WASP 2040 CLAY provides accurate, fast and accessible printing using all ceramic materials.

Innovated Design

2040 Clay 3D Printer has an extruder pressure chamber mounted into the machine so that you only need to provide compressed air to get an integrated clay solution. The print platform has an adjustable sliding-system on bearings that guarantee excellent stability.

Delta Geometric System

2040 Clay uses the Delta Geometric System, which consists of 3 main arms connecting to the extruder, which move up and down independently. The position of the extruder is calculated by using trigonometric functions.

User Friendly Interface

2040 Clay offers a new 32 bit industrial quality proprietary board for improved speed, an LCD Display, built-in Wi-Fi and SD Card compatibility. It is also compatible with Windows, Mac, and Linux operating systems.

Technicial Specifications10

Building Volume
Ø200 x h 400 mm
Min Layer Height
0,5 mm
Max Print Speed
150 mm/s
Acceleration
500 mm/s2
LDM WASP Extruder
3.0, nozzle 1.5, 2, 3 mm (standard)
Luer lock nozzle adapter with conical nozzles
1.2mm, 1.5mm
Product Dimensions
440 x 490 x 870 mm
Product Weight
40 kg
Power Consumption
220/240 V 50/60 Hz
Required Air Compressor
min pressure 8 bar
Ceramic Mixtures: Clay, porcelain, pottery, etc.
